Standard GB5169 Glow Wire Test Apparatus , Hot Wire Ignition Test Flammability Temperature Test

GLOW WIRE TEST APPARATUS OF MODEL 5114

Glow Wire Tester could be applicable to ignition hazard test, combustibility test of electronic industry, home electronic appliance and materials. The glow wire apparatus and common test procedure is to simulate the effect of thermal stressed witch may be produced by heat sources such as glowing elements or overloaded resistors, for short periods, in order to assess the fire hazard by a simulation technique.

Glow Wire Tester's crust and important parts are made by Stainless Steel, Sculpt daintily, endure smoke corrupt, high automatism, temperature control part made by import material, high precision, numeric shows time and temperature and reliable.

Technology data:

1. accord with standard:GB5169/IEC60695
2. SIZE:1120W*600D*1020H
3. Glow wire: Φ4mm Ni/Cr(80/20)
4. Thermocouple: Φ0.5mm K style
5. Heating temperature: 50℃ ～1050 ℃
6. Sample test pressure:1.0N+-0.1N
7. Sample move speed :10mm/s~25mm/s(forward backward independent speed)
8. Burning time :0.01s~99.99s(can be set)
9. Risetime: 0.01s~99.99s
10. Hold buring time: 0.01s~99.99s

Features:

1)7inch programmable touch screen controller

2)PLC+stepper motor position control

3)USB test report data leading out

4)Import control component

5)one touch timing device

6)advanced controlling temperature system and testing temperature system

7)armoured glass window
